Secondary 3 distance–time and speed–time graphs become easier when students ask what each axis means before calculating gradient or area.
On a distance–time graph, gradient represents speed. On a speed–time graph, gradient represents acceleration while area represents distance travelled. The same-looking triangle on the page can therefore answer different questions depending on the axes.
For rate foundations, read Secondary 3 Ratio, Proportion, Percentage and Rate. For graph foundations, read Secondary 3 Functions and Graphs.
Distance–Time Graph: Gradient Is Speed
If distance rises from 20 km to 80 km while time rises from 0.5 h to 1.5 h, speed over that interval is (80−20)/(1.5−0.5)=60 km/h.
The gradient unit is kilometres per hour because vertical units are kilometres and horizontal units are hours.
A Horizontal Distance–Time Segment Means Stationary
If time continues but distance does not change, gradient is zero.
The object is stationary relative to the reference point during that interval.
A horizontal line on a different type of graph may mean something else, so always read axes first.
Steeper Distance–Time Gradient Means Greater Speed
On the same axes, a steeper upward segment means distance is increasing faster per unit time.
Comparing slopes is a quick qualitative way to compare speeds before calculating exact values.
Returning Toward the Start
If a graph shows distance from a fixed starting point and the plotted distance decreases with time, the traveller is moving back toward the start.
The gradient is negative because the plotted distance-from-start is decreasing. The physical speed itself is still nonnegative; the sign reflects direction in the chosen graph quantity.
Worked Example: Piecewise Journey
A traveller moves from 0 km at 0 h to 30 km at 0.5 h, stays at 30 km until 0.75 h, then reaches 60 km at 1.25 h.
First speed=30/0.5=60 km/h.
Stationary interval lasts 0.25 h.
Final speed=(60−30)/(1.25−0.75)=30/0.5=60 km/h.
The equal slopes show equal speeds before and after the stop.
Average Speed Uses Total Distance Over Total Time
If the traveller covers 60 km in total over 1.25 h, average speed across the entire journey including the stop is 48 km/h.
Do not average the two moving speeds and ignore the stationary time.
Speed–Time Graph: Gradient Is Acceleration
Suppose speed rises from 4 m/s to 16 m/s over 6 seconds.
Acceleration=(16−4)/6=2 m/s².
The gradient unit m/s per second simplifies to m/s².
Horizontal Speed–Time Segment Means Constant Speed
If speed remains 12 m/s for 5 seconds, acceleration is zero.
The object is still moving; its speed is simply not changing.
This contrasts with a horizontal distance–time segment, which means no change in distance.
Area Under a Speed–Time Graph Gives Distance
For constant speed 12 m/s over 5 s, the area is a rectangle: 12×5=60 m.
This is speed×time, the same relationship as distance=speed×time.
Worked Example: Uniform Acceleration
A vehicle accelerates uniformly from 0 to 20 m/s over 8 s.
The speed–time graph forms a triangle under the line.
Distance travelled=1/2×8×20=80 m.
Acceleration=20/8=2.5 m/s².
The same graph gives both distance from area and acceleration from gradient.
Worked Example: Accelerate, Cruise, Decelerate
A vehicle accelerates from 0 to 12 m/s in 4 s, travels at 12 m/s for 6 s, then decelerates uniformly to rest in 3 s.
Distance during acceleration=1/2×4×12=24 m.
Cruising distance=6×12=72 m.
Deceleration distance=1/2×3×12=18 m.
Total distance=114 m.
Gradient Needs Two Points on the Same Segment
On a straight graph segment, choose two clear points and calculate vertical change divided by horizontal change.
If the graph is curved, the gradient changes. A tangent can estimate instantaneous rate at one point where required by the student’s course.
Units Can Change the Numerical Answer
A speed of 72 km/h equals 20 m/s.
If time is measured in seconds and distance in metres, convert before mixing with km/h.
Unit discipline prevents a correct formula from producing an incorrect magnitude.
Distance–Time Versus Displacement–Time
A true distance travelled cannot decrease, but a graph labelled “distance from home” can decrease as someone returns home.
A displacement–time graph can be negative depending on direction and reference point.
The label determines the interpretation. Do not infer more physics than the graph actually states.
Read Motion Stories From Graphs
A graph can often be described before calculations:
- steep rise → fast movement;
- gentle rise → slower movement;
- horizontal distance–time segment → stopped;
- horizontal speed–time segment → constant speed;
- upward speed–time slope → increasing speed;
- downward speed–time slope → decreasing speed.
These verbal interpretations help catch formula misuse.
Common Errors
- using gradient as speed on a speed–time graph;
- using area as distance on a distance–time graph;
- treating a horizontal speed–time line as stationary;
- averaging speeds directly without using total distance and total time;
- ignoring stop time in average speed;
- mixing hours and seconds;
- calculating gradient from points on different segments;
- forgetting triangle and trapezium areas under speed–time graphs.
A Five-Question Independent Check
- A distance–time graph rises 45 km in 0.75 h. Find the speed.
- What does a horizontal segment on a distance–time graph mean?
- Speed rises from 5 m/s to 17 m/s in 4 s. Find the acceleration.
- An object travels at 9 m/s for 8 s. Find the distance from the speed–time graph.
- A vehicle accelerates uniformly from rest to 10 m/s in 6 s. Find the distance travelled.
Answers
Question 1: 60 km/h. Question 2: stationary relative to the plotted distance reference. Question 3: 3 m/s². Question 4: 72 m. Question 5: 30 m.
Exam-Day Routine
- read both axes and units;
- decide whether gradient or area answers the question;
- split piecewise graphs into simple intervals;
- calculate total distance and total time separately for averages;
- convert units before mixing quantities;
- check the graph story against the numerical answer.
