Secondary 3 bearings and scale-drawing questions become much more reliable when direction, angle convention and distance scale are kept separate. A bearing tells direction. A scale tells how a drawing length relates to a real distance. Trigonometry may connect the two, but only after the diagram is interpreted correctly.
For the wider year plan, read Secondary 3 to SEC Mathematics — Build the Exam Runway Before Secondary 4.
Three-Figure Bearings Are Measured Clockwise From North
A bearing is written with three digits from 000° to 359°.
East is 090°, South is 180°, West is 270°.
A direction 40° clockwise from North is written 040°, not 40° if three-figure bearing notation is required.
The Starting Point Matters
The bearing of B from A is measured at A, from the north line through A toward B.
The bearing of A from B is measured at B. These are reverse directions and usually differ by 180°.
If B from A is 065°, then A from B is 245°.
Worked Example: Reverse Bearing
The bearing of Q from P is 132°. Find the bearing of P from Q.
Add 180°: 132°+180°=312°. So the reverse bearing is 312°.
If the original bearing were greater than 180°, subtract 180° instead.
Draw the North Line at Every Relevant Point
In multi-point questions, draw a vertical north reference at each point used for a bearing.
The north lines are parallel. This often lets students use alternate or corresponding angle relationships to connect bearings to triangle angles.
Worked Example: Find an Interior Angle From Bearings
From point A, B has bearing 050° and C has bearing 120°.
The angle BAC between the two directions is 120°−50°=70°.
This works because both bearings are measured clockwise from the same north line at A.
Scale Drawings Use Like Units
A map scale 1:25,000 means 1 cm on the map represents 25,000 cm in reality if centimetres are being compared.
Since 25,000 cm=250 m, a map distance of 6.4 cm represents 1,600 m or 1.6 km.
Convert only after the scale relationship is established.
Worked Example: Real Distance to Map Distance
A real route is 3.75 km long on a 1:50,000 map.
3.75 km=375,000 cm. Map distance=375,000/50,000=7.5 cm.
The map measurement should be much smaller than the real distance. That scale check catches reciprocal errors.
Scale Drawing and Bearings Together
Suppose a station B is 4 km from A on bearing 060°.
On a map where 1 cm represents 0.5 km, draw a 8 cm line from A at bearing 060°.
The bearing determines the direction. The scale determines the length. Mixing the two decisions is a common source of error.
Worked Example: Bearing Triangle With Sine Rule
Suppose B is 8 km from A on bearing 030°, and C is 11 km from A on bearing 100°. The included angle BAC is 70°.
If the school programme includes non-right-angled triangle trigonometry, side BC can be found using the cosine rule:
BC²=8²+11²−2(8)(11)cos70°.
BC≈11.17 km.
The bearing work produced the included angle. The trigonometry then uses the triangle.
Bearings From a Diagram
If a diagram gives the direction line but no bearing, measure or calculate the clockwise angle from north according to the information supplied.
Do not measure a printed diagram unless measurement is explicitly part of the task. Use angle facts when exact information is available.
Worked Example: North-East Style Description
A direction 35° east of north corresponds to bearing 035°.
A direction 35° north of east corresponds to 090°−35°=055°.
The reference direction changes the answer, even though both statements contain the words north, east and 35°.
Grid and Coordinate Checks
A bearing of 090° should move purely east on an ordinary north-up grid. A bearing of 180° should move south.
These cardinal directions provide fast checks before the question becomes more complicated.
Common Errors
- measuring anticlockwise instead of clockwise;
- measuring from east instead of north;
- forgetting three-figure notation;
- using the north line at the wrong point;
- forgetting reverse bearings differ by 180°;
- mixing map and real-world units;
- using the scale factor in the wrong direction;
- measuring a diagram that is not meant to be measured.
A Five-Question Independent Check
- Write east as a three-figure bearing.
- Find the reverse bearing of 078°.
- From A, B has bearing 025° and C has bearing 110°. Find angle BAC.
- On a 1:20,000 map, 5 cm represents how many kilometres?
- A real distance of 2.4 km is shown on a 1:40,000 map. Find the map distance in cm.
Answers
Question 1 gives 090°. Question 2 gives 258°. Question 3 gives 85°. Question 4 gives 1 km. Question 5: 2.4 km=240,000 cm, so map distance=6 cm.
Exam-Day Routine
- draw north at the correct point;
- mark the clockwise bearing;
- convert to an interior triangle angle if needed;
- write the scale relationship in matching units;
- choose geometry or trigonometry only after the diagram is clear;
- check that direction and distance are both plausible.
